| Model | FD15T-I | FD18T-I | FD15T-JB | FD18T-JB | FD15T-JC | FD18T-JC | |
| Power Type | Diesel | ||||||
| Rated Load Capacity | Q(kg) | 1500 | 1800 | 1500 | 1800 | 1500 | 1800 |
| Load Centre | C(mm) | 500 | |||||
| Rated Lift Height | H3(mm) | 3000 | |||||
| Free Lift Height | H2(mm) | 100 | |||||
| Fork Size (L×W×T) | mm | 920×120×35 | 1070×120×40 | 920×120×35 | 1070×120×40 | 920×120×35 | 1070×120×40 |
| Mast Tilt Angle (F/R, α°/β°) | deg | 6°/12° | |||||
| Fork Overhang (Wheel Center to Fork Face) | X1(mm) | 409 | |||||
| Rear Overhang | X2(mm) | 470 | 470 | 470 | 470 | 470 | 470 |
| Ground Clearance (Bottom of Mast) | H7(mm) | 110 | |||||
| Length to Face of Fork (Without Fork) | L1(mm) | 2285 | 2285 | 2285 | 2285 | 2285 | 2285 |
| Overall Width | B1(mm) | 1082 | |||||
| Mast Lowered Height | H1(mm) | 2025 | |||||
| Mast Extended Height (With Backrest) | H4(mm) | 4055 | |||||
| Overhead Guard Height | H5(mm) | 2160 | |||||
| Travel Speed (No Load) | km/h | 14.5 | |||||
| Lifting Speed (Full Load) | mm/sec | 560 | |||||
| Lowering Speed (Full Load) | mm/sec | 450 | |||||
| Engine Model | NC485BPG | C240NKFC-01 | 4TNE92 (EuⅢ & EPAⅢ) | ||||
| Engine Manufacturer | XINCHAI | ISUZU | YANMAR | ||||
| Rated Output / r.p.m. | kw | 30/2600 | 34.5/2500 | 33/2450 | |||
| Rated Torque / r.p.m. | N·m | 131/1800 | 139/1800 | 150/1600 | |||
